DTL-A Bimetallic Cable Lug

Type

Φ

D

d

L1

L2

W

S

L

DTL-10(A)

8.5

10

5.3

30

22

16

2.5

64

DTL-16(A)

8..5

11

6.3

33

24

16

2.8

70

DTL-25(A)

8.5

12

7.3

36

25

18

3.0

75

DTL-35(A)

10.5

14

8.5

42

30

20

3.2

85

DTL-50(A)

10.5

16

9.5

43

31

23

3.4

90

DTL-70(A)

12.5

18

11.5

50

36

26

3.6

102

DTL-95(A)

12.5

21

13.5

53

40

28

4.0

112

DTL-120(A)

14.5

23

15.1

55

42

30

4.5

120

DTL-150(A)

14.5

25

16.5

57

45

34

5.0

126

DTL-185(A)

17.0

27

18.5

60

46

37

5.5

133

DTL-240(A)

17.0

30

20.7

62

50

40

6.3

140

DTL-300(A)

21.0

34

23.5

66

59

46

7.3

160

DTL-400(A)

21.0

38

26.2

72

61

50

7.6

168
